Panel Mount 12 Keys Metal Mechanical Keyboard Zinc Alloy IP65 For Access Entry Kiosk

Name: Panel Mount 12 Keys Metal Mechanical Keyboard Zinc Alloy IP65 For Access Entry Kiosk
Brand: IKB-MKB
Price: 1 USD

Quality Panel Mount 12 Keys Metal Mechanical Keyboard Zinc Alloy IP65 For Access Entry Kiosk for sale

Brand Name : IKB-MKB

Certification : CE, FCC, ROHS, IP65, IP68, ISO 9001-2015

Place of Origin : Shenzhen, China

MOQ : 1pc

Price : US

Supply Ability : 3000psc/month

Delivery Time : ASAP Within 2 weeks upon payment confirmed

Packaging Details : Each keyboard to one box, several boxes to one carton.

Model Number : K-TEK-A12KP-AC-BL

Panel mounting : Rear panel mounting

Key numbers : 12 keys

Materials : Zinc alloy

Switch life : More than 5 million of operations

Dimensions : 69.0mm x 72.00mm

Interface : Dot matrix

Payment Terms : Full payment in advance, Western Union, T/T, Paypal

Contact Now

IP65 Vandal Proof Panel Mount 12 Keys Metal Keypad For Access Entry Kiosk

Descriptions:
12 keys compact format IP 65 vandal proof metal dot matrix keypad with Zinc alloy chromed keys and frame, with industrial PCB with carbon-on-gold key switch with long stroke 2.0mm, rear panel mounted, dot matrix keypad without electronics controller. Blue backlight Included.
Dimensions: 69.0mm x 72.00mm (front panel)

Main components
1) Alloy chrome-plated button and framework
2) Natural electrical conductive silicon rubber
3) Epoxy resin gilding

PCB Users choice
1)Button chrome-plated colors: polished or sandblasted chrome.
2) Zinc alloy – plated of the framework’s colors: polished or sandblasted chrome

MECHANICAL DATA	ELECTRICAL DATA
Keys: 12 keys, Zinc alloy Key Size: 10.0mm x 10.0mm Key travel: 2.0mm Switch life: more than 5 million of operations.	Working voltage: DC 9v+/-5% Lifespan: >5 years Key switch: Natural electrical conductive silicon rubber Pin pitch space: 2.54mm Working temperature: -20℃+60℃ Storage temperature:-30℃+70℃ Operating RH: 30-90% Atmospheric pressure 80~106kPa Force 160-180 grams, nimble dial-up Contact resistance<100 Ω

Actual Photo:

Panel Mount 12 Keys Metal Mechanical Keyboard Zinc Alloy IP65 For Access Entry Kiosk
